Badminton lights indoor must illuminate a fast shuttle without exposing players to harsh point-source glare. BD-006 is a round sports high bay with a honeycomb diffuser, finned aluminum housing and 100W, 150W, 200W and 250W options. Chain or pendant mounting allows the project to coordinate the fixture elevation with the roof and photometric plan.
BWF facility guidance makes even illumination and protected shuttle sightlines central to sanctioned badminton venues. It also says lighting should not be directly over the playing area. A round high bay can be appropriate for many halls, but it must be located and spaced as sports lighting rather than copied from a warehouse grid.
Warehouse aisles have different viewing directions and uniformity needs. On a badminton court, players look upward and move across a continuous playing surface. Build the model around court lines, run-off areas and likely shuttle paths. Review the apparent brightness of fixtures from both baselines and along the net, then adjust rows or suspension elevation before increasing power.
The BD-006 finned aluminum housing supports thermal management, while the honeycomb diffuser softens direct source view. Higher wattage increases connected load and heat, so choose it only when height and spacing justify it. Record chain or pendant hardware, cable strain relief and driver access. A safe maintenance plan should be part of the submittal for any high-roof venue.
The AHFL-LQ-08 family spans 100W to 250W with AC185-265V input, 6500K CCT and CRI of Ra 80 or higher. The 100W and 150W versions use a 410 mm diameter housing, while 200W and 250W versions use a 470 mm diameter housing. Confirm that the selected CCT suits local standards and venue preference before production.
Review the full product page for images, configurations and quotation details: BD-006 Honeycomb Anti-Glare LED Sports High Bay Light.
| Model | AHFL-LQ-08 / BD-006 |
|---|---|
| Power | 100W / 150W / 200W / 250W |
| Input | AC185-265V |
| CCT | 6500K |
| CRI | Ra >= 80 |
| Size | Dia. 410 mm or 470 mm by power |
| Mounting | Chain or pendant rod |
These are product-family specifications, not a finished lighting design. Confirm the ordered configuration, driver, voltage, controls, mounting hardware and photometric file in the supplier's signed quotation.
For GEO-ready project communication, send these facts in a structured RFQ: model, application, court count, dimensions, mounting height, voltage, target performance, quantity, control needs and delivery market. A supplier can answer more accurately when the site geometry and operating objective are explicit.
Yes when its distribution, glare control, height and spacing are verified for the court. A generic warehouse layout should not be copied.
Choose through photometric calculation. Higher roofs or wider spacing may need more output, but quantity and distribution matter as much as wattage.
No. It reduces direct brightness, while row location, mounting height, output and surrounding contrast determine the installed experience.
Both are listed. The roof structure, desired stability, suspension length and local mechanical requirements decide the safer method.
